ECON-10

Recovery rate of up to 81.2%
Capacity - 25kg
Light, small and portable
Independent filtration system

Product Description

Description :

ECON-10F is an endeavor in reverting and recycling the oxides which occurs during working of a Wave Soldering Machine in order to reduce production cost, create a greener environment and assist the quality process. Use special stirring system to melt the tin residues in the tin container and separate tin and ash in the separation container by the high speed of screw rotation.

Features:

Highly effective recycling of the solder waste, up to 81.2% yield.(according to tin remaining proportion in slag)
No need to add any chemicals or reducers to the process uses physical separation to ensure a good quality product
Button controls, digital temperature control sheet, accurate temperature control
All stainless steel tank clean convenience
316 grade stainless mixing bowl with an10kg capacity with heating power for complete mixing
Dross automatic feeding system, automatic feed screw
Electronic liquid level alarm, manually put tin
Automatic separation of tin and tin ash, into the tin and tin-ash collection device
Small size, light weight, move convenience
Independent smoke filtration system (Optional).

Technical Parameters:

Item	Parameter
Mixing Motor	1ø 220V 90W
Mixing Heating Power	1.5KW
Mixing Capacity of Bottom Tin	10KG
Temperature Scope	0-350°C
Heating-up time	50min
Feeding Time	Continuous 3-4kg /40min
Dimension Electrical box size	L525W280H650 L140W330H390
Total Power Consumption	1.6KW
Normal running power	0.4KW
Power	1ø 220V 50HZ
Net Weight	Appro*42kg
